The 12881FSP segment‑type LCD display is a dedicated display accessory specially designed by Hengxunchuang (HxcDisplay) for the DSE5110 diesel generator controller, manufactured in Guangdong, China. The product features an STN positive‑mode display with a yellow‑green LED backlight, offering stable industrial performance and supporting operation across a wide temperature range. It provides a 1:1 direct fit for the DSE5110 deep‑sea controller, requiring no additional calibration and enabling plug‑and‑play installation. This segment‑type screen operates at a 1/4 duty cycle and a 1/3 bias voltage, with a working voltage of 5V and a viewing angle of 6:00. The overall module dimensions are 70.0W × 40.9H × 2.8T mm, while its operating temperature range spans from –20°C to +70°C, and its storage temperature range is –30°C to +80°C, making it fully compatible with demanding industrial conditions. The product supports both standard and custom sizes, and offers excellent cost‑effectiveness for b
Learn More
The 015MP segment‑code LCD display is a medical‑device‑specific display accessory launched by Hengxunchuang (HxcDisplay), manufactured in Guangdong, China. This model is an HTN positive‑type monochrome seven‑segment LCD, driven at a 1/4 duty cycle and 1/3 bias voltage, with a operating voltage of 3.3 V and a viewing angle of 6:00. It features a soft blue LED backlight and does not include a built-in controller IC. The module measures 90.0 W × 49.0 H × 2.8 T mm, operates within a temperature range of 0°C to +60°C, and can be stored between −20°C and +70°C, making it well suited for standard temperature conditions in medical settings. The product is available in standard sizes and also supports custom dimensions; its design is tailored specifically for medical devices, offering eye‑friendly display performance and stable power supply. With excellent cost‑effectiveness for bulk orders, it is widely used in various portable diagnostic instruments, medical monitoring equipment, home health‑
Learn More
The 61661MP segment‑code LCD display is an LCD module specially designed by Hengxunchuang (HxcDisplay) for various types of instruments and equipment, manufactured in Guangdong, China. This product is a 7‑segment segment‑code display that employs a TN gray‑film positive‑type display mode, with a drive configuration of 1/4 duty and 1/3 bias. It operates at 3.3 V, offers a viewing angle of 6:00, features a backlight‑free design, and does not include a controller IC. The module measures 62.5 W × 57.0 H × 2.8 T mm, functions within a temperature range of −20°C to +70°C, and can be stored between −30°C and +85°C, exhibiting industrial‑grade wide‑temperature performance. The product delivers clear imaging, low power consumption, and supports custom segment‑code patterns and size customization. With high cost‑effectiveness for bulk orders, it is widely used in temperature and humidity monitors, precision measuring instruments, smart home monitoring devices, laboratory meters, and other equipm
Learn More
The 066RP segment‑code LCD display is a dedicated display module developed by Hengxunchuang (HxcDisplay) specifically for vehicle instrument panels, manufactured in Guangdong, China. The product employs a VA negative‑mode display, with a drive configuration of 1/4 duty and 1/3 bias, operates at 5.0 V, offers a 6:00 viewing angle, features a backlight‑free design, and includes no built-in controller IC. The module measures 116.7 W × 47.0 H × 2.8 T mm, functions within a temperature range of −30°C to +80°C, and can be stored between −40°C and +90°C, providing an exceptionally wide operating temperature span. The screen maintains high visibility even under direct sunlight, delivers stable low‑power performance, and is fully compatible—1:1—with the YAMAHA FZ V2 motorcycle instrument panel. Additionally, it supports custom segment‑code patterns and dimensions, making it suitable for a variety of outdoor vehicle instruments, including motorcycles and electric vehicles, and serving as a premi
Learn More
The 2.7-inch PMOLED organic light-emitting display is an industrial-grade self-illuminating display module launched by Hengxunchuang (HxcDisplay), manufactured in Guangdong, China. The product features the SPD0301 controller IC, a resolution of 128x64, and a black-background-yellow-character display with excellent contrast. The module uses a plug-in 30-pin interface and supports multiple communication protocols, including Parallel, I2C, and 4-wire SPI. It operates at a supply voltage of 1.65–3.3V, has no additional backlight, and relies on PMOLED self-illumination technology. The overall module dimensions are 73W×40.24H×2.0T mm, with an operating temperature range of -40℃ to +70℃ and a storage temperature range of -40℃ to +80℃, offering ultra-wide temperature tolerance and ultra-low power consumption. It supports both standard and custom sizes, making it suitable for industrial control equipment, power terminals, precision instruments, medical devices, and many other applications, and
Learn More
The 2.42-inch PMOLED organic light-emitting display is an industrial-grade display module that Hengxunchuang (HxcDisplay) specializes in wholesale and customization, manufactured in Guangdong, China. This screen features a resolution of 128x64, is equipped with the SPD0301 controller IC, and uses a plug-in 24-pin interface, supporting multiple communication protocols including Parallel, I2C, and 4-wire SPI. Its operating voltage ranges from 1.65 to 3.3V. Leveraging the self-emissive nature of PMOLED, it requires no additional backlight. The module measures 60.5W × 37H × 1.8T mm, operates within a temperature range of -40°C to +70°C, and can be stored at temperatures from -40°C to +80°C. It boasts wide-temperature operation and ultra-low power consumption. The product is available in standard sizes and also supports personalized customization, making it ideal for applications such as medium-sized industrial instruments, IoT terminals, automotive master controllers, and professional medi
Learn More
The 1.54-inch PMOLED organic light-emitting display is a miniaturized self-emissive display module launched by Hengxunchuang (HxcDisplay), manufactured in Guangdong, China. It features a resolution of 128x64, is driven by the SPD0301 chip, and uses a plug-in 24-pin interface compatible with both Parallel and I2C communication protocols, operating at a voltage of 1.65–3.3V. Leveraging the self-emissive nature of PMOLED, it requires no additional backlight. The module measures 42.04W×27.22H×1.4T mm, with an operating temperature range of -40℃ to +70℃ and a storage temperature range of -40℃ to +85℃, offering wide-temperature operation and ultra-low power consumption. The product supports standard and custom sizes, making it suitable for field monitoring terminals, portable medical devices, in-vehicle auxiliary displays, smart wearables, and other applications, serving as a high-quality display component for portable electronics and compact terminal devices.
Learn More
The 1.3-inch PMOLED organic light-emitting display is a compact, lightweight self-emissive display module developed by Hengxunchuang (HxcDisplay), manufactured in Guangdong, China. It features a resolution of 128x64, integrates the SSD1315 controller IC, and uses a soldered 30-pin interface, supporting multiple communication protocols including Parallel, I2C, and 4-wire SPI. Its operating voltage ranges from 1.65 to 3.5V. Leveraging the self-emissive nature of PMOLED, it requires no additional backlight. The module measures 32.42W × 21.36H × 1.4T mm, making it exceptionally thin and compact. Its operating temperature spans -30℃ to +70℃, with a storage temperature range of -40℃ to +80℃, offering ultra-wide temperature tolerance and ultra-low power consumption. The product supports both standard and custom sizes, and is widely used in precision industrial instruments, IoT terminals, small in-vehicle displays, portable wearable devices, and more—making it an ideal choice for display compo
Learn More
HCG12864-686 is a COG graphic dot-matrix LCD display manufactured by Hengxunchuang (HxcDisplay), produced in Guangdong, China, and specifically designed for AMF20 and AMF25 diesel generator set controllers. This product features an STN semi-transmissive positive‑mode display, equipped with an ST7567 controller IC, driven at 1/65 duty and 1/9 bias, operating at 3.3V, with a 6:00 viewing angle, and includes a yellow‑green LED backlight. The module measures 89.50W×49.80H×5.70T mm, operates within a temperature range of -20℃ to +70℃, and can be stored between -30℃ and +80℃, offering industrial‑grade wide‑temperature performance. The product is highly compatible with the AMF series generator controllers, allowing direct replacement without any adjustments; it supports both standard and custom sizes, provides stable supply, and offers excellent cost‑effectiveness for bulk purchases, making it a dedicated display accessory for generator set and industrial power equipment maintenance and integ
Learn More
HCG13233-07 is a COG graphic dot-matrix LCD display produced by Hengxunchuang (HxcDisplay), manufactured in Guangdong, China. It is specifically designed for Emcp4.1 and Emcp4.2 diesel generator controllers, compatible with part numbers 339-9755-00 and M282-06. The product features an STN semi-transmissive positive‑mode display, equipped with the NT7532 controller IC, driven at 1/33 Duty and 1/6 Bias, operating at 3.0V with a viewing angle of 6:00, and includes a yellow‑green LED backlight. The module measures 133.8W×68.00H×8.10T mm, functions within a temperature range of -30℃ to +70℃, and can be stored at -30℃ to +85℃, delivering excellent performance in low‑temperature conditions. This screen is precisely compatible with Emcp series controllers, allowing direct replacement without any adjustments, and supports both standard and custom sizes. With a stable supply and high cost‑effectiveness for bulk purchases, it is an ideal replacement display component for generator sets, industria
Learn More
